MANUTEC Industrial HC-EP 220 Industrial Gear Oil
MANUTEC Industrial HC-EP 220 Industrial Gear Oil
Estimate delivery costs
Your postcode lets us show accurate delivery costs before you add to basket. We use it only to calculate shipping rates — it isn't stored or shared.
Couldn't load pickup availability
MANUTEC Industrial HC-EP 220 - Heavy-Duty Extreme-Pressure Gear Oil
MANUTEC Industrial HC-EP 220 is a premium ISO VG extreme-pressure industrial gear oil engineered for severe-duty gearboxes, bearings and circulating systems operating under high load, intermittent shock loading and elevated temperatures.
Formulated using high-purity base oils and a fortified EP additive system, it delivers exceptional anti-scuff performance, extended service life and outstanding film strength where standard oils cannot cope.
This oil is ideal for slow-to-medium speed heavy industrial gear drives where reliability, uptime and wear control are essential.
Recommended Applications
- Enclosed Industrial Gearboxes (spur, helical, bevel, planetary) requiring ISO VG 220 EP oil
- Heavy Loaded Reduction Gear Units in crushers, mixers, conveyors and mills
- Mining, Quarrying and Aggregate Equipment subject to shock loading
- Steel, Cement, Paper and Processing Plants using circulating lubrication systems
- Heavily Loaded Bearings operating at slow speeds
- Agitators, Extruders, Presses and Drive Systems requiring high-viscosity EP oils
- Gearboxes in Harsh, Dusty or Wet Environments needing strong corrosion and water separation properties
- Suitable for: AGMA 9005-E02: 252.4 AIST (US Steel) 224 David Brown S1.53.101 DIN 51517 Part III ISO 12925-1 CKC Suitable for steel mill gearbox applications where shock loading conditions impose unique stresses
Key Benefits
- Extreme-Pressure Protection: EP additives create a sacrificial, load-bearing film that prevents wear, scuffing and micropitting under heavy loading and lubrication stress.
- Thermally Stable Formula: Resists thinning at high temperature and maintains viscosity for consistent gear film strength.
- Long Service Life: Excellent oxidation resistance reduces sludge, varnish and acidic byproducts - ideal for long drain intervals in circulating systems.
- Corrosion & Rust Protection: Protects internal gearbox surfaces and bearings during downtime, start-up and humid conditions.
- Water Separation & Foam Control: Fast air release and strong demulsification help prevent foam, aeration and water-induced bearing damage.
- Smooth & Quiet Operation: Reduced friction improves mechanical efficiency and lowers overall noise.
Typical Test Data
| Parameter | Typical Value |
| Density @ 15°C (ASTM D4052) | 0.90g/cm³ |
| Flash Point (ASTM D92) | >200°C |
| Kinematic Viscosity @ 40°C (ASTM D445) | 220 mmª/s |
| Kinematic Viscosity @ 100°C (ASTM D445) | 19.5 mmª/s |
| Pour Point (ASTM D97) | -12°C |
| Viscosity Index (ASTM D2270) | 101 |
Please note: These are typical values and do not constitute a specification. Actual Performance may vary.
Specifications
| Product Ref | AZO |
|---|---|
| Volume (litres) | 20 |
| Weight (kg) | 23 |
| Lead time (working days) | 7 |
Delivery Terms
The delivery of a tank can be confusing as each manufacturer offers a slightly different service and lead time. Please refer to our Delivery Information page. Standard tank deliveries are "kerbside", which means the tank will be delivered to the kerb only and not positioned further. Should you have specific delivery requirements or restrictions, please contact us to discuss.
Tanks over 2,500L — articulated lorry, customer offload
These tanks are delivered on an articulated vehicle (approximately 16.5m long × 2.6m wide × 3m high) which has no offloading on board. It is the customer's responsibility to offload the tank, which may require a telehandler or forklift.
Curtain-sided vehicles are also used, so please note that if there are obstacles or overhanging branches on the road to the delivery site, the driver may refuse to drive to the location due to the risk of damaging the vehicle. Please let us know about any obstructions before delivery so we can arrange alternative transport.
18-tonne tail-lift HGV
This vehicle is roughly the size of the largest bin lorries — approximately 8.2m long × 2.6m wide × 4m high, and often curtain-sided. If there are overhanging branches, these vehicles will not attempt the route, so a smaller vehicle should be requested.
Tanks are lowered to the ground but not positioned, as this is a kerbside delivery. If a smaller vehicle is required, email sales@fueltankshop.co.uk quoting your order number and name.
HIAB delivery
HIAB delivery is available but must be requested, and carries an additional cost. Email sales@fueltankshop.co.uk quoting your order number and name, and we'll come back to you with a price.
Accessories
Most accessories are delivered within 1–3 working days. Certain products and postcodes may take longer — check the product page for current information. If you need them sooner we can sometimes offer a next-day service; please contact us to discuss. If an item is out of stock we'll advise the expected lead time, and you're free to cancel for a full refund.
Returns Information
Customers may return items within 14 calendar days, as set out in section 7 of our Terms & Conditions.
All items must be returned unused. Refunds cannot be issued for used or previously installed items.
Please be aware that returning a tank can be complicated and expensive, so do check you're ordering the correct item — we strongly suggest checking the dimensions carefully before you buy.
How to return an item
- Complete the form on our returns page with details of your order.
- Once your request is approved, we'll issue a Returns Authorisation Number (RAN) along with instructions on how and where to return your order, and any costs involved.
- Please do not return any goods without this authorisation. Goods cannot be accepted without a valid RAN.
- Returns are not accepted at our Minehead office. Please wait until we contact you before returning anything.
