ZVA 25 High Speed Fuel Pump Nozzle With Safety Break Swivel & Magnet
Product Ref: ZVA.25SBC
Home Delivery
United Kingdom mainland delivery from FREE ex VAT
Free Parcel Delivery (Highlands & Islands are charged a higher fee than standard)
login to saveZVA 25 High Speed Fuel Pump Nozzle With Safety Break Swivel & Magnet Description
ZVA 25 High Speed Fuel Pump Nozzle With Safety Break Swivel & Magnet
ZVA is recognised across the UK and Europe and can be found on most forecourts. This high-speed model, with a max flow rate of up to 140L/min, is perfect for fueling larger vehicles such as trucks, agricultural and plant machinery. This version is supplied with a magnet in the guard as certain dispensers require a magnet to turn them on/off.
This version has the built-in safety break swivel for added operator security, protecting your operation from accidental damage if a vehicle pulls away when the nozzle is left in the filling position.
The nozzle is robustly made to have a long life-cycle, and as such, is equipped with a stainless steel tip to prevent damage from wear and tear.
Supplied with a 3 position stay open trigger latch, which can be disabled if required (must be disabled on retail forecourts & when used with B100). The automatic shut-off prevents overfill and environmentally damaging spills, protecting operations from loss of revenue at the same time. The nozzle comes with a 1 year warranty as standard.
Why Buy?
- ZVA nozzles are used on most retail fuel stations they have fantastic reliability and useability
- Popular choice in the diesel, HVO commercial fuel dispensing sector
- Safety break swivel, protects against accidental damage if a vehicle drives off with the nozzle still in the tank
- Supplied with a magnet in the guard, as certain dispensers require a magnet to turn them on/off
- This nozzle copes with up to 140 litres per minute, which is ideal for vehicles with large fuel tanks, trucks, agricultural and plant machinery.
- ATEX certified, for use in flammable environments and meets the requirements of DSEAR (Dangerous Substances and Explosive Atmosphere Regulations).
- Stainless steel tipped nozzle outlet spout tip for longevity
- Inlet swivel supplied as standard to help prevent premature hose wear
- A must when dispensing fuel with an electric pump as helps prevent spills with its automatic shut off facility
Key Features:
- Suitable with diesel, HVO, biodiesel up to B100 & kerosene
- Includes a safety break swivel, designed to separate if a vehicle drives off with the nozzle still in the tank
- Supplied with a magnet in the guard as certain dispensers require a magnet to turn them on/off
- Stainless steel tipped spout for longer life, spout diameter 31mm
- High speed 140 litres per minute version
- Automatically shuts off the flow of fuel when the vehicle tank is full
- Flow rate 15 - 140 litres per minute
- 1" BSPP female inlet swivel
- Approved for resale
- 3-position stay open latch (must be disabled on retail forecourts & when used with B100)
- For use with electric pumps only
- Max pressure 50psi (3.5 bar)
- 1 years parts warranty
- Full range of spares available
- ATEX certified
- The safety break swivel sheers between 175 ? 265lbs when force is applied
