950 Litre Highway Diesel Bowser Twin Axle

Product Ref: 950ROADTWIN

Comes supplied with 1/2" BSP feed and return connections

Customer Offloading Steel Diesel, Gas Oil, HVO Diesel, Gas Oil, HVO Diesel, Gas Oil, HVO Bunded, Transportable
  • Volume: 950ltr
  • Dimensions: L:3963mm W:1555mm H:1708mm
  • Lead time approx. 2 - 3 working days

    Custom Delivery Required

    Delivery price on application.

    Choose Pump Required:

    updown
    You may also need:
    Boot Cleaner Premium
    Boot Cleaner Premium
    £463.00 ex VAT
    (£555.60 inc VAT)
    65 Litre Fuel Spill Kit - Round Drum OSK6
    65 Litre Fuel Spill Kit - Round Drum OSK6
    £85.00 ex VAT
    (£102.00 inc VAT)

    950 Litre Highway Diesel Bowser Twin Axle Tank Compliance

    The 950 litre bunded twin axle diesel EU highway bowser is constructed from a polyethylene inner tank to ensure a clean fuel storage solution, secured in a steel outer bund.

    This bunded diesel twin axle EU highway bowser comes with lockable rear door, four lifting points and two fork sockets (for when the tank is out of the chassis).

    Complete with a fully certified single axle highway towable trailer. The A-frame trailer is fully welded and manufactured from steel and then galvanised as standard, Painted chassis are available upon request

    The 950 litre bunded twin axle diesel EU highway bowser is fully U.N. certified for 10 YEARS for the storage and transportation of fuel. Please see link https://www.hse.gov.uk/cdg/commonproblems/bowsers.htm

    950 Litre Highway Diesel Bowser Twin Axle Downloadable Documents

    950 Litre Highway Diesel Bowser Twin Axle Video

    950 Litre Highway Diesel Bowser Twin Axle Description

    950 Litre UN Approved Bunded Diesel EU Certified Bowser - Highway Bowser Twin Axle

    950 litre (208 gallons) road towable bunded twin axle diesel bowser.  Certified UN 1202 (For Road Haulage).

    Like to view the bowser ? Please click on the video tab below for a walk around showing the design & features of this bowser

    Chassis: Constructed from 100 x 50 RSC fully welded with front standing plate and an ‘A’ frame drawbar. Hot dip galvanized

    Axle/Suspension: Knott-Avonride Twin 1500kg torsion beam axle fitted with 200 x 50 auto reverse brakes

    Wheels & Tyres: 4 No 175/13 x 8 ply Tyres on 4 Stud rims

    Coupling: : Knott-Avonride 3000kg auto reverse coupling fitted with either a choice of 40mm eye or 50mm ball, break away cable and spring assisted hand brake lever

    Ancillary Equipment: Moulded Tandem mudguards and mud flaps. Heavy duty jockey wheel c/w Side reflectors, front reflectors, full road lighting c/w 13 pin plug and 7 pin adaptor

    Outer bund tank:

    • Cylindrical in section with removable top section for tank access

    • Rear access door fitted with stainless steel hinge and fully lockable

    • Bund contains 110% of inner tank

    • 4 lifting eyes

    • Fork truck sockets for use when tank is not fitted in a chassis

    Inner Fuel Tank:

    • Constructed from translucent, heavy duty, polyethylene with a capacity of 980 litres

    • 2" Filler cap & chain

    • 1" Manual vent valve

    • ½” Top Mounted suction and return fittings

    • Ball valve in base of tank to pump

    • Pressure relief valve in the top of the tank.

    Pump:

    • K1 semi rotary located in the rear of the tank for back up

    • 4.5m Delivery Hose & Manual Nozzle

    • Inline water/particle filter

    • All contained within lockable bund area

    • 12V Pump upgrade available at extra cost

    Finish:

    • Primer & 2 top coats - single British Standard (BS) colour

    • Galvanized chassis

    Optional (Please contact us for price):

    • Spare Wheel & Tyre, & Holder
    • Flow Meter



    Please note - image for illustrative purposes only

    950 Litre Highway Diesel Bowser Twin Axle Specification

    • Product Code: TE
    • Delivery Options: Customer Offloading
    • Made From: Steel
    • Suitable For Fuel: Diesel, Gas Oil, HVO
    • Tank Type: Bunded, Transportable
    • UN Certified / Approved for Transport under ADR: Yes
